Schmersal 101059694 Medium-Duty Position Switch Fork Roller Lever 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101059694

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Medium-Duty Position Switch
Brand SCHMERSAL
Actuating Element Fork Lever
Actuating Speed 1 mm/min
Contact Opening (2) 6 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Mechanical Life 10000000 Operations
Switching Type Slow Action
Contact Configuration 1NO+1NC
Rated Current 4 A
Rated Voltage 400 VAC
Actuator Type Fork Roller Lever
Cable Cross Section 1.5 sq-mm
Contact Material Silver
Housing Material Grey Cast Iron, Galvanized
Standards and Approvals ENIEC 60947-5-1

Documents

IPD Product Catalogue V17
SCHMERSAL Datasheet

Certificate

Other Certification

CAD Blocks & Dimensions
