Schmersal 101163278 Position Switch Plunger 1NO-1NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101163278

1

Specifications

Product Type	Position Switch
Brand	Schmersal
Series	422 plunger S
No. of N/C Contacts	1
Type of Switching Output	Mechanical
Contact Configuration	1NO+1NC
Rated Current	4A (AC-15)
Rated Voltage	400V AC (AC-15)
Terminal Type	Screw
Thermal Test Current	16A
Actuator Type	Plunger
Cable Cross Section	1.5 sq-mm
Connecting Capacity	(2) 6 mm
Contact Material	Silver
Housing Material	Grey cast iron, galvanised
Depth	63mm
Height	97mm
Weight	1,250 g
Width	106mm
IP Rating	IP65
Ambient Temperature	-40 ... +90 °C
Standards and Approvals	CCC, EC000030, ENIEC 60947-5-1, INMETRO

Documents

IPD Product Catalogue V17

SCHMERSAL Datasheet

Certificate

Other Certification

CAD Blocks & Dimensions

Dimensions

Dimensions
