Schmersal 101170462 Position Switch Plunger NC Grey Cast Iron Galvanized Silver Contact

Product Code: 101170462

  • Rated current of 4 A
  • Durable grey cast iron housing
  • IP65 protection rating
  • ENIEC 60947-5-1 compliant
  • Silver NC contacts
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Position Switch
Brand SCHMERSAL
Actuating Element Plunger
Actuating Speed 1 mm/min
Actuator Type Plunger
Cable Cross Section 1.5 sq-mm
Contact Configuration NC
Contact Material Silver
Contact Opening (2) 6 mm
Degree of Protection IP65
Enclosure Coating Material Painted
Fuse Rating 16 A gG D-Fuse
Housing Material Grey Cast Iron, Galvanized
Rated Current 4 A
Standards and Approvals ENIEC 60947-5-1

Description

<p>This industrial-grade switch is crafted for durability and reliability, making it a solid choice for various commercial applications. Constructed from grey cast iron with a galvanized finish, the housing ensures robust protection against environmental factors, aligning with its IP65 rating. This degree of protection signifies that the device is dust-tight and can withstand low-pressure water jets from any direction—a crucial feature for maintaining operational integrity in challenging environments.</p><p>The switch adheres to EN/IEC 60947-5-1 standards, guaranteeing compliance with international safety and performance benchmarks. Its contact configuration consists of normally closed (NC) contacts made from silver, providing excellent conductivity and minimizing electrical resistance. Designed to handle a rated current of 4 A, this product supports efficient energy management within your system.</p><p>A notable aspect of this switch is its plunger actuator type, which allows precise control over operations. With an actuating speed as slow as 1 mm/min, it offers meticulous performance where gradual activation is necessary—ideal for sensitive or high-precision applications.</p><p>For enhanced safety measures, the switch accommodates a fuse rating of 16 A gG D-Fuse. This ensures that in case of overloads or short circuits, the system remains protected by interrupting excessive currents effectively.</p><p>The cable cross-section capacity stands at 1.5 sq-mm, supporting adequate wiring capabilities without compromising on space or efficiency within your setup. Furthermore, the dual contact opening design features two openings each measuring 6 mm—facilitating straightforward integration into existing systems while ensuring reliable connectivity.</p><p>In summary, this device blends robust construction with technical precision to meet demanding industrial needs efficiently and safely.</p>
