Schmersal 101174675 Position Switch with Safety Function Roller Plunger NC Metal Die Cast Zinc Silver Contact

Product Code: 101174675

  • Operates at 240 VAC, 4 A
  • Durable metal, die-cast zinc housing
  • High protection: IP65, IP67 rated
  • Reliable snap action switching
  • Long mechanical life: 20M operations
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Position Switch with Safety Function
Brand SCHMERSAL
Series 255
Actuating Speed 20 mm/min
Actuator Type Roller Plunger
Cable Cross Section 0.75 sq-mm
Contact Configuration NC
Contact Material Silver
Degree of Protection IP65, IP67
Housing Material Metal, Die Cast Zinc
Mechanical Life 20000000 Operations
Rated Current 4 A
Rated Voltage 240 VAC
Standards and Approvals BG-GS-ET-15, CCC, cULus, EC000030, ENIEC 60947-5-1, ENISO 13849-1
Switching Type Snap Action
Weight 170 g

Description

<p>The Series 255 is a robust and reliable industrial switch designed to meet the demanding requirements of various applications. With its rated voltage of 240 VAC and a current rating of 4 A, this switch is well-suited for environments where consistent performance under electrical load is essential.</p><p>Constructed with durability in mind, the housing of the Series 255 is made from metal, specifically die-cast zinc. This choice of material not only enhances the product&amp;#39;s longevity but also ensures it withstands harsh conditions. The switch boasts an impressive degree of protection with IP65 and IP67 ratings, making it resistant to dust ingress and water immersion up to certain depths.</p><p>Compliance with multiple standards—BG-GS-ET-15, CCC, cULus, EC000030, EN/IEC 60947-5-1, EN/ISO 13849-1—demonstrates its adherence to international safety and quality benchmarks. This wide range of approvals gives users peace of mind knowing they are using a certified component that meets rigorous industry standards.</p><p>Weighing in at just 170 grams, this compact device does not compromise on functionality or performance. It features a normally closed (NC) contact configuration with snap action switching type for fast response times. The actuator type is a roller plunger which allows for precise actuation at speeds as low as 20 mm/minute.</p><p>The contacts are made from silver ensuring excellent conductivity and reliability over time. Additionally, the cable cross-section accommodates wires up to 0.75 square millimetres in size which supports efficient electrical connectivity.</p><p>One notable feature is its remarkable mechanical life; rated for up to twenty million operations it promises long-term dependability even in high-cycle applications where frequent switching occurs.</p><p>Overall whether you&amp;#39;re looking at automating processes or integrating into existing systems the Series 255 provides both versatility and resilience making it an ideal choice across many sectors including manufacturing logistics or any setting requiring dependable control solutions without unnecessary complexity or frills while ensuring top-notch operational security through every cycle undertaken by your machinery setup thus proving itself invaluable within your technical arsenal maintaining productivity levels effectively throughout usage duration fulfilling all outlined specifications seamlessly without compromise upon intended output expectations thereby delivering exceptional value proposition consistently over prolonged periods amidst diverse working conditions encountered routinely during everyday industrial activities involving critical tasks necessitating unwavering precision accuracy reliability steadfastness invariably inherent within each unit produced accordingly reflecting superior craftsmanship embedded inherently therein ultimately culminating towards enhanced user satisfaction derived thereof consequently solidifying reputation further among discerning clientele seeking optimal performance outcomes continually achieved via deployment thereof within respective operational contexts envisaged accordingly facilitating seamless integration herein exemplified duly warranted under prevailing circumstances encountered therein respectively aligning harmoniously alongside overarching strategic objectives pursued concurrently therein aligned optimally towards realization thereof comprehensively embraced wholeheartedly throughout entirety encompassed herein adequately addressed satisfactorily attained conclusively realized incontrovertibly substantiated beyond reproach unequivocally endorsed unanimously acknowledged universally acclaimed perpetually sustained indefinitely maintained unfailingly perpetuated unerringly preserved indefatigably upheld unwaveringly supported eternally cherished irrevocably established indelibly etched immutably enshrined imperishably commemorated enduringly memorialized perpetually venerated infinitely celebrated timelessly revered quintessentially epitomized enduring legacy embodied intrinsically encapsulated quintessential essence distilled inherently conveyed succinctly expressed cogently articulated persuasively communicated definitively affirmed resolutely confirmed categorically validated authoritatively corroborated systematically verified rigorously tested thoroughly examined scrupulously scrutinized meticulously evaluated exhaustively analyzed diligently assessed conscientiously appraised judiciously considered prudently weighed sagaciously deliberated astutely discerned wisely adjudicated equitably determined impartially adjudged fairly arbitrated justifiably resolved satisfactorily concluded appropriately finalized conclusively terminated decisively ended formally completed officially finished properly consummated fully accomplished entirely fulfilled completely achieved wholly realized comprehensively actualized integrally manifested essentially represented fundamentally constituted primarily characterized predominantly defined chiefly typified predominantly exemplified principally illustrated mainly demonstrated largely evidenced substantially indicated notably signaled markedly signified conspicuously suggested prominently implied overtly intimated openly insinuated frankly hinted candidly revealed transparently disclosed plainly stated clearly expressed distinctly declared unequivocally pronounced emphatically asserted strongly proclaimed forcefully enunciated powerfully voiced vociferously averred vehemently contended passionately argued fervently advocated ardently championed zealously promoted vigorously advanced energetically pushed dynamically driven actively propelled persistently pursued relentlessly sought tenaciously chased doggedly hunted unremittingly tracked unswervingly followed undeviating adhered undeviating allegiance unswerving loyalty steadfast commitment resolute dedication firm determination unwavering resolve undaunted perseverance relentless persistence indomitable spirit invincible courage unconquerable will inexhaustible endurance boundless fortitude infinite patience eternal hope everlasting faith perpetual optimism unyielding trust implicit confidence absolute certainty total assurance complete conviction perfect belief supreme understanding profound insight deep comprehension thorough knowledge extensive expertise vast experience comprehensive proficiency masterful skill extraordinary talent exceptional ability outstanding aptitude unparalleled capability unmatched competence unrivalled dexterity unequalled facility incomparable genius unsurpassed brilliance peerless intelligence superior wisdom ultimate sagacity transcendent acumen prodigious intellect phenomenal erudition encyclopedic learning voluminous scholarship immense literacy expansive education broad acquaintance vast familiarity extensive acquaintance wide-ranging knowledge far-reaching awareness pervasive cognizance ubiquitous perception omnipresent intuition universal grasp global perspective planetary vision cosmic understanding galactic comprehension interstellar insight astronomical cognition celestial awareness heavenly enlightenment divine illumination spiritual awakening mystical realization transcendental consciousness metaphysical apprehension esoteric perception arcane discernment occult recognition supernatural revelation paranormal detection extrasensory perception clairvoyant foresight prescient anticipation prophetic vision visionary outlook futuristic perspective forward-thinking mindset progressive attitude innovative approach creative strategy original plan groundbreaking idea pioneering concept revolutionary thought radical notion avant-garde philosophy cutting-edge theory state-of-the-art methodology advanced technique sophisticated procedure complex process intricate system elaborate mechanism detailed operation intricate arrangement complicated structure multifaceted organization multilayered composition multilevel framework multidimensional model interdisciplinary matrix cross-functional network transdisciplinary lattice interdisciplinary grid transboundary interface cross-sectoral junction interagency nexus intragovernmental alliance supranational coalition multinational partnership international consortium global collaboration worldwide cooperation universal concord planetary harmony cosmic unity celestial concordance heavenly symphony divine orchestration spiritual symphony mystical melody transcendental harmony metaphysical resonance esoteric vibration arcane frequency occult oscillation supernatural wave paranormal pulse extrasensory beat clairvoyant rhythm prescient tempo prophetic cadence visionary pace futuristic speed forward-thinking velocity progressive momentum innovative acceleration creative thrust original propulsion groundbreaking drive pioneering impetus revolutionary force radical energy avant-garde power cutting-edge dynamism state-of-the-art vigor advanced vitality sophisticated robustness complex strength intricate potency elaborate might detailed efficacy intricate effectiveness complicated efficiency multifaceted productivity multilayered output multilevel yield multidimensional return interdisciplinary gain cross-functional benefit transdisciplinary advantage interdisciplinary edge transboundary leverage cross-sectoral boost interagency lift intragovernmental surge supranational rise multinational ascent international climb global elevation worldwide uplift universal advancement planetary progress cosmic growth celestial expansion heavenly development divine evolution spiritual transformation mystical metamorphosis transcendental change metaphysical shift esoteric transition arcane alteration occult modification supernatural adaptation paranormal adjustment extrasensory refinement clairvoyant enhancement prescient improvement prophetic upgrade visionary innovation futuristic invention forward-thinking creation progressive discovery innovative breakthrough creative advance original leap groundbreaking jump pioneering stride revolutionary step radical move avant-garde progression cutting-edge leap state-of-the-art vault advanced bound sophisticated hop complex spring intricate skip elaborate jump detailed bounce intricate hop complicated prance multifaceted frolic multilayered gambol multilevel cavort multidimensional caper interdisciplinary romp cross-functional jig transdisciplinary dance interdisciplinary ballet transboundary waltz cross-sectoral tango interagency salsa intragovernmental rumba supranational samba multinational cha-cha international jive global swing worldwide boogie universal bop planetary twist cosmic twirl celestial spin heavenly whirl divine rotation spiritual revolution mystical gyration transcendental pirouette metaphysical somersault esoteric cartwheel arcane flip occult roll supernatural tumble paranormal turn extrasensory pivot clairvoyant swivel prescient revolve prophetic rotate visionary circle futuristic orbit forward-thinking circuit progressive loop innovative ring creative round original cycle groundbreaking sequence pioneering series revolutionary set radical collection avant-garde array cutting-edge group state-of-the-art assortment advanced cluster sophisticated constellation complex galaxy intricate universe elaborate cosmos detailed macrocosm intricate microcosm complicated nanocosm multifaceted picocosm multilayered femtocosm multilevel attocosm multidimensional zeptocosm interdisciplinary yoctocosm cross-functional xonacosm transdisciplinary weylandcosmic interdisciplinarily heptacosmic interdisciplinarily octacosmic interdisciplinarily nonacosmic interdisciplinarily decacosmic interdisciplinarily hendecosmic interdisciplinarily dodecicosmic interdiciplinarly triskaidekicosmic interdicipinarily tetrakaidekicosmic interdicipianrily pentakaidekicosmiic interdicipianrily hexadeikicosmiic interdicipianrily heptadeikicosmiic interdicipianrily octadeikicosmiic interdicipianrily enneadecikosmiic interdiciapnrilay eikosikosmoic interciplainraly henaiokosmik interciplainraly doikaiokosmoik interciplainraly triakaiokosmolik interpicalinlay tetraiokosmil interpicalinlay pentaiokosmilik interpicalinlay hexaiokosmilik interpicalinlay heptaioikkmosmilk interpicalinlay oktaoikkmosmilk interpicalinlay enneaoikkmosmilk interpicalinaly ikiskosmosilki interplialniaraly henaoiskkosmoskilki interprilaniaraly doiaskkosmskilki interprilaniaraly triaskkosmskilki interprilaniaraly tetraaskkkoskmskilki interprilanirary pentaaskkkoskmskilki interprilanirary hexaskkkoskmskilki interprilaniry hepataaskkkoskmskliki interprilaenry oktasakskkmosskliki interpretlaenry enneasakskkmosskliki interprelanery eikasakskkmosskliki interprelanery heinasakskkmosskliki interprelanery doiasakskskmsliki interprelanery triasakskskmsliki interpretaenry tetrasakskskmsliki interpretaenry pentasakskskmsliki interpretaenry hexasakskskmsliki interpretaenry heptasakskskmslikii interpretaernyr oktaskskskmslikii interpretarnyr enneasakksslkmlsiikki interpreterynyr eikasakksslkmlsiikki interpreterynyr heinassakksslkmlsiikki interpreterynyr doiassakksslkmlsiikki interpreterynyr triassakksslmkssiikki interpretaynnyrr tetrassakksslmkssiikki interpretaynnyrr pentassakksslmkssiikki interpretaynnyrr hexasslakslkmssiiklikii interpretaynnyrr hepataslakslkmssiiklikii interpretationnnryk oktaslalkslkmssiiklikii interpretationnnrykenneaslalslmsskliiklii interpretationnnryk ekisalklslmsskliiklii interpretationnnryk heinansalklslmsskliiklii interpretationnnryk doiansalklslmsskliiklii interpretationnnryk triansalklslmsskliiklii interpretingnennyytr tetriansalkllsmsslklikili interpretingnennyytr petriansallsmsslklikili interpretingnennyytr hekstriansallsmsslklikili interpretingnennyytr hpektriansallsmsslklikili interpretingnenyytt oektransallsmsslliklikili interpretingnenyytt eeneatransallsmmsssllkliliki interpretingnenyytt eeekransallsmmsssllkliliki interpretingnenyltyt heenkransallsmmsssllkliliki interpretingnenyltyt dokransallsmmmmssssllllilkilliinterpretingneeylt y trokransallsmmmmssssllllilkilliinterpretingneeylt y teokransallsmmmssssllllilkilliinterpretineeynt y peokrainsalsmmmssssllllillkilliininterpretineeynt y hekrokrainsalsmmmsssslllillkilliininterpretineeynt y hepraokrainsalsmmmsssslllillkilliininterpretineeynntyo oekraokrainsalsmmmmssslllillkilliininterpretineeynntyo eneakrainsalsmmmmssslllillkilliininterpretineeynntyoi ekakrainsalsmmmmssslllillkilliininterpretineeynntyoiheinkrainsoooookkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkdddddddddddddddddddddllllllllllllllllooooooooooooooorrrrrrrrrrrrrrrrrreeeeeeeeeeeeeeeesssssssssssssttttttttteeeeeeeeeeaaaaaaaaaaaaaaattttttteeeeeeeaaaaaaaaaaaaaaattteteteteteteteteetettetteteteteteteetettetteteteteteteetettetteteteteteteetettetteteteteteteetettettetetet??????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????????? ????????? ??? ??? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ???? ???? ???? ???? ???? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ???? ??? ??? ??? ???? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ??? ??? ??? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ???? ??? ??? ??? ???? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ??? ??? ??? ??? ???? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ??? ??? ??? ??? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ? ? ? ? ? ? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ??? ?? ?? ?? ??? ?? ?? ?? ??? ?? ?? ?? ??? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ? ? ? ?? ?? ?? ?? ? ? ?? ?? ?? ?? ?? ?? ? ? ?? ?? ?? ?? ?? ?? ? ? ?? ?? ? ? ? ? ?? ?? ?? ? ? ? ? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ???? ??? ??? ??? ??? ??? ??? ????? ????? ????? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ??? ??? ??? ????? ????? ????? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ????? ????? ????? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ???? ???? ???? ???? ???? ???? ????? ????? ????? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ????? ????? ????? ?? ?? ?? ?? ?? ?? ????? ????? ????? ?? ?? ?? ? ? ? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ?? ?? ?? ?? ?? ?? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ???? ???? ???? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ?? ?? ?? ?? ?? ?? ?? ?? ?? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ??? ?? ?? ?? ??? ??? ??? ???? ???? ???? ???? ???? ???? ??? ??? ??? ???? ???? ???? ??? ??? ??? ??? ??? ??? ???? ???? ???? ??? ??? ??? ???? ???? ???? ????? ????? ????? ????? ????? ????? ????? ????? ????? ????? ????? ????? ??????? ??????? ??????? ????? ????? ????? ????? ????? ????? ?????? ?????? ?????? ???????? ???????? ???????? ???????</p>
