Specifications

Product Type	Safety Switch with Separate Actuator
Brand	SCHMERSAL
Series	EX-AZ 16
No. of N/C Contacts	2
No. of N/O Contacts	1
Rated Insulation Voltage (Ui)	250 V
Switching Principle	Slow Action, Positive Break NC Contact
Contact Configuration	1NO+1NC
Terminal Type	Screw terminals
Mechanical Durability	10000000 Cycles
Contact Material	Silver
Housing Material	Plastic, Reinforced Glass Fibre
Depth	30 mm
Height	90 mm
Weight	1300 g
Width	52 mm
Operating Temperature	-25 to 65 deg C
IP Rating	IP65
Standards and Approvals	EN IEC 60947-1, EN IEC 60947-5-1
Enclosure Dimensions	55 mm L x 64 mm H
