Schmersal 103007625 EX Belt Alignment Switch Glass Fibre Reinforced Thermoplastic

Product Code: 103007625

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type Belt Alignment Switch
Brand Schmersal
Series EX-441 Belt Alignment Switch
No. of N/C Contacts 1
No. of N/O Contacts 1
Rated Insulation Voltage (Ui) 400 V
Rated Current 4A
Rated Voltage 400VAC
Terminal Type Screw
Thermal Test Current 16 A
Contact Material Gold-plated silver
Housing Material Grey cast iron, galvanised
Weight 160 g
IP Rating IP65,IP66,IP67
Ambient Temperature -20 ... +60 °C
Standards and Approvals BG-GS-ET-19, ENIEC 60947-5-1

Documents

IPD Product Catalogue V17
Instructions
SCHMERSAL Datasheet

Certificate

EU Declaration of Conformity
Other Certification

CAD Blocks & Dimensions
