Specifications

Product Type	Position Switch
Brand	Schmersal
Series	M 330 roller lever 7H
No. of N/C Contacts	1
No. of N/O Contacts	1
Rated Insulation Voltage (Ui)	250 VAC
Type of Switching Output	Snap Action
Contact Configuration	1NO+1NC
Rated Current	2.5A (AC-15)
Rated Voltage	230V AC (AC-15)
Terminal Type	Screw
Thermal Test Current	6A
Actuator Type	Roller lever
Cable Cross Section	2.5 sq-mm
Connecting Capacity	(2) 0.5 mm
Contact Material	Silver
Housing Material	Light-alloy diecast, paint finish
Depth	40mm
Height	232 mm
Weight	445 g
Width	40mm
IP Rating	IP65
Ambient Temperature	-30 ... +160 °C
Standards and Approvals	ENISO 13849-1
