Specifications

Product Type	QS
Brand	ABB
Application	To protect the systems against the transient overvoltage (lightning)
Connection Type	Plug-In
Lightning Impulse Current Iimp (10/350µs)	2 kA
Max. Continuous Operating Voltage (AC/DC)	275 V
Suitable For	Protect The Systems Against The Transient Overvoltage (Lightning)
Power Loss	29 mW
Rated Current	40 kA
Rated Short Circuit Current	100 kA
Rated Voltage	230 VAC
Type	Plug-in
Nominal Voltage	230 V AC, 400 V AC
Voltage Protection Level Up	1.25 kV, 1.4 kV, 1.5 kV
Max. Discharge Current Imax (8/20µs)	40 kA
Short Circuit Current Rating	100 kA
Nominal Discharge Current Inom (8/20µs)	20 kA
No. of Poles	4
Mounting Method	DIN-Rail
Mounting Type	DIN Rail
Terminal Size	25 mm2
Depth	58 mm
Height	88 mm
Weight	0.48 kg
Width	71.2 mm
No. of Modules Width	4
IP Rating	IP20
