Specifications

Product Type	Surge Protective Device
Brand	ABB
Connection Type	Plug-In
Degree of Protection	IP20
Depth	76.7 mm
Height	95.8 mm
Lightning Impulse Current	12.5 kA
Mounting Type	DIN Rail
Number of Conductors	4
Number of Poles	4
Power Loss	63 mW
Rated Current	80 kA
Rated Short Circuit Current	100 kA
Rated Voltage	230/400 V
Suitable For Use With	Protect The Systems Against The Transient Overvoltage (Lightning)
Version	Plug-in
Voltage Protection Level	1.4 kV
Weight	0.6 kg
Width	71.2 mm
