Specifications

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)	NC 5.8 kW; NO 5.8 kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)	NC 1.3 kW; NO 1.3 kW
Product Type	DIN Contactors
Brand	ABB
Series	ESB
No. of N/C Contacts	2
No. of N/O Contacts	2
No. of Poles (NO/NC)	2NO/2NC
Rated Control Supply Voltage (Us)	12 V
Rated Impulse Withstand Voltage (Uimp)	6 kV
Rated Insulation Voltage (Ui)	500 V
Rated Operational Current AC-1/AC7a (Ie)	(NC) 25 A; (NO) 25 A
Rated Operational Current AC-3/AC7b (Ie)	(230 V) NC 6 A; (230 V) NO 9 A
Utilization Category	AC-1 According to EN IEC 60947-4-1
Contact Configuration	2NC+2NO
Rated Current	25 A
Rated Frequency	Control Circuit 400 Hz; 50 Hz/60 Hz
Rated Power	1.31 kW
Rated Voltage	400 VAC
Mounting Type	DIN Rail
Depth	65 mm
Height	85 mm
Weight	0.245 kg
Width	36 mm
Pollution Degree	3
Operating Temperature	-25 to 55 deg C
IP Rating	IP20
Ambient Temperature	-25 ... +55 °C
Standards and Approvals	IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L
Voltage Type for Actuation	AC/DC
