Specifications

Rated Operational Power AC-1/AC7a 230V 1 Phase (Pe)	NO 5.8 kW
Rated Operational Power AC-1/AC7a 400V 3 Phase (Pe)	NO 17.3 kW
Rated Operational Power AC-3/AC7b 230V 1 Phase (Pe)	NO 1.3 kW
Rated Operational Power AC-3/AC7b 400V 3 Phase (Pe)	NO 4 kW
Product Type	DIN Contactors
Brand	ABB
Series	ESB
No. of N/C Contacts	0
No. of N/O Contacts	3
No. of Poles (NO/NC)	3NO
Rated Control Supply Voltage (Us)	230 ... 240 V
Rated Impulse Withstand Voltage (Uimp)	6 kV
Rated Insulation Voltage (Ui)	500 V
Rated Operational Current AC-1/AC7a (Ie)	(NO) 25 A
Rated Operational Current AC-3/AC7b (Ie)	(230 V) NO 9 A; (400 V) NO 9 A
Utilization Category	AC-1 According to EN IEC 60947-4-1
Contact Configuration	3NO
Rated Current	25 A
Rated Frequency	Control Circuit 400 Hz; 50 Hz/60 Hz
Rated Power	1.3 kW
Rated Voltage	400 VAC
Terminal Type	Screw
Mounting Type	DIN Rail
Depth	65 mm
Height	85 mm
Weight	0.23 kg
Width	36 mm
No. of Modules Width	2
Pollution Degree	3
Operating Temperature	-25 to 55 deg C
IP Rating	IP20
Ambient Temperature	-25 ... +55 °C
Standards and Approvals	IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 61095 UL 60947-1 UL 60947-4-1 IEC 60335-2-40 A2L
Voltage Type for Actuation	AC/DC
