<p>The manual motor starter is a robust and reliable choice for industrial and commercial applications, offering a blend of performance and safety features tailored to meet rigorous technical requirements. With a rated voltage of 690 VAC and current of 1.6 A, this device is designed to handle substantial electrical loads efficiently.</p><p>Engineered with versatility in mind, it supports both 50 Hz and 60 Hz frequencies, making it suitable for diverse operational environments. The power loss stands at a modest 5.1 W, ensuring energy efficiency without compromising on functionality.</p><p>This starter employs a rotary handle actuator type which simplifies operation while maintaining precision control over motor functions. Its screw terminal type connection ensures secure electrical connections with tightening torque ranging from 0.8 to 1.2 N-m, providing reliability in high-demand settings.</p><p>Built to withstand challenging conditions, the device boasts an IP20 degree of protection against solid objects and an IP3 degree of pollution resistance, underscoring its durability in varied environmental conditions. The wire stripping length is specified at 9 mm for straightforward installation processes.</p><p>Measuring at a compact width of 45 mm, height of 90 mm, and depth of 86.75 mm, it fits seamlessly into tight spaces without sacrificing ease of access or functionality. It operates effectively within temperatures as low as -50&#176;C up to +80&#176;C.</p><p>Safety compliance is assured with adherence to standards such as IEC/EN 60947-1/-2/-4-1 and UL certifications including UL 60947-1/-4-1 along with IEC standards like IEC 60335-2-40 A2L.</p><p>Delivering a rated power output of up to 0.55 kW makes it ideal for small motors while its rated short circuit current capacity reaches up to an impressive 20 A with a breaking capacity standing strong at 100 kA—ensuring dependable performance even under fault conditions.</p><p>The unit&#39;s electrical durability extends through an impressive lifecycle of up to 50,000 cycles which signifies long-term reliability for continuous operations.</p><p>For precise customization according to specific needs, the current setting range allows adjustment between 1 A and the maximum rated value of this model’s design parameters (1–1.6 A). Additionally equipped with thermomagnetic switching type technology offering effective overload release mechanisms set precisely at intervals starting from just below full load capacities (at exactly one amp).</p><p>Incorporating user-friendly control elements via turn button interface further enhances operability by simplifying adjustments during routine maintenance checks or emergency interventions when necessary—all wrapped within sturdy construction materials capable enough not only meeting but exceeding standard expectations across multiple industry sectors globally today!</p>
