Specifications

Product Type	Load Break Switch Kit
Brand	ABB
Series	OT
Application	Manufacturing, commercial buildings, infrastructure
Position of Line Terminals	Top In - Bottom Out Bottom In - Top Out
Rated Current (In)	40A
Rated Impulse Withstand Voltage (Uimp)	8 kV
Rated Insulation Voltage (Ui)	750 V
Rated Operating Voltage	Main Circuit 750 V
Rated Operational Current AC21-A (Ie)	40 A
Rated Operational Current AC22-A (Ie)	40 A
Rated Operational Current AC23-A (Ie)	23 A
Rated Short Time Withstand Current (Icw)	for 1 s 0.5 kA
Power Loss	at Rated Operating Conditions per Pole 1.6 W
Rated Current	40 A
Rated Voltage	750 VAC/VDC
Special Functions	No
Mechanical Life	20000
No. of Poles	4P
Rated Thermal Current (Ith)	40 A
Colour	Red, Yellow
Handle Type	Selector
Mounting Type	Base
Depth	56 mm
Height	68 mm
Weight	0.125 kg
Width	48 mm
Pollution Degree	3
IP Rating	Front IP20
Standards and Approvals	IEC 60947-3 / UL 508 / CSA C22.2 No. 14
Included Components	Handle and Shaft

LBS 40A 4P BASE MOUNT ABB KIT C/W R/Y DOOR HANDLE 22MM FIX IP65, UP TO 10MM2 CABLE
