Specifications

Product Type	CPU Module
Brand	IDEC
Series	FC6A MicroSmart PLC
Development Software	Automation Organizer / WindLDR
Analog Resolution	10 bits
Digital Inputs	9
Digital Outputs	7
Output Ratings	12V DC, 0.5A per point
Input Ratings	12V DC; 5mA/pt (high speed), 6mA/pt (normal/middle speed)
Input Type	12V DC Sink/Source
Output Type	Transistor Sink
Power Consumption	3.0W
Supply Voltage	12VDC
Terminal Type	Screw Terminals
Analog Inputs	1
Mounting Method	DIN Rail/Panel
Depth	73.0 mm
Height	90.0 mm
Width	95.0 mm
Storage Temperature	-25 to +70°C
Operating Temperature	-25 to 65?
IP Rating	IP20
Ethernet Port Speed	10/100 Mbps
Ethernet Ports	1
Expandable Communications	Yes
Serial Ports	1
USB Port	1
Supported Ethernet Protocols	Modbus TCP
Supported Serial Protocols	Modbus RTU
Hazardous Location Ratings	Class I Division 2
Compliance Standards	CE, UL, TUV
