Specifications

Product Type	Expansion Module
Brand	IDEC
Series	FC6A MicroSmart PLC
Development Software	Automation Organizer / WindLDR
Analog Resolution	16-bit
Digital Inputs	0
Digital Outputs	0
Analog Outputs	0
Input Ratings	Voltage 0-10V, -10 to +10V (1MO max); Current 0-20mA, 4-20mA (50O max); Overload: 13V/40mA
Input Type	Voltage/Current
Power Consumption	0.27W
Supply Voltage	24V DC
Terminal Type	Screw terminals
Analog Inputs	2
Mounting Method	DIN Rail/Panel
Depth	73.0 mm
Height	90.0 mm
Width	23.6 mm
Storage Temperature	-25 to +70°C
Operating Temperature	-25 to 65?
IP Rating	IP20
Hazardous Location Ratings	Class I Division 2
Compliance Standards	CE, UL, TUV
