Specifications

Product Type	Expansion Module
Brand	IDEC
Series	FC6A MicroSmart PLC
Development Software	Automation Organizer / WindLDR
Analog Resolution	15-bit
Digital Inputs	0
Digital Outputs	0
Analog Outputs	0
Input Ratings	Thermocouple, Thermistor (1MO min); Detection current: 0.1mA max; Overload: 13V/40mA.
Input Type	Thermocouple/Thermist
Power Consumption	0.30W
Supply Voltage	24V DC
Terminal Type	Screw terminals
Analog Inputs	8
Mounting Method	DIN Rail/Panel
Depth	73.0 mm
Height	90.0 mm
Width	23.6 mm
Storage Temperature	-25 to +70°C
Operating Temperature	-25 to 65?
IP Rating	IP20
Hazardous Location Ratings	Class I Division 2
Compliance Standards	CE, UL, TUV
