IDEC FC6A-N08A11 Expansion Module 120VAC 8 Digital Inputs 11-Pin

Product Code: FC6A-N08A11

1

Specifications

Product Type	Expansion Module
Brand	IDEC
Series	FC6A MicroSmart PLC
Development Software	WindLDR
Channel Isolation	Isolated
Digital Inputs	8
Digital Outputs	0
Analog Outputs	0
Input Ratings	17 mA/pt
Input Type	100 to 120V AC
Power Consumption	0.27W
Supply Voltage	100-120V AC
Terminal Type	Screw terminals
Analog Inputs	0
Mounting Method	DIN Rail/Panel
Depth	73.0 mm
Height	90.0 mm
Width	17.6 mm
Storage Temperature	-25 to 70 °C
Operating Temperature	-25 to 65?
IP Rating	IP20
Hazardous Location Ratings	Class I Division 2
Compliance Standards	CE, UL, TUV

Documents

IPD Product Catalogue V17

IDEC Brochure

IDEC Datasheet

Manual

Certificate

cUL_Certification

EU Declaration of Conformity

UL Certification
