Specifications

Product Type	Expansion Module
Brand	IDEC
Series	FC6A MicroSmart PLC
Development Software	WindLDR
Channel Isolation	Optocoupler-isolated circuit
Digital Inputs	16
Digital Outputs	0
Analog Outputs	0
Input Ratings	7 mA/pt
Input Type	24V DC sink/source
Power Consumption	0.27W
Supply Voltage	24V DC
Terminal Type	MIL Terminal
Analog Inputs	0
Mounting Method	DIN Rail/Panel
Depth	73.0 mm
Height	90.0 mm
Width	23.6 mm
Storage Temperature	-25 to 70 °C
Operating Temperature	-25 to 65?
IP Rating	IP20
Hazardous Location Ratings	Class I Division 2
Compliance Standards	CE, UL, TUV
