Specifications

Product Type	Pushbutton
Brand	IDEC
Series	HW
No. of N/C Contacts	1
No. of N/O Contacts	1
Rated Voltage	240 V AC
Terminal Type	Finger Safe Spring Terminal
Contact Block Thermal Current (Ith)	10 A
Contact Block Rated Current (Ie)	AC-12: (440 V) 2 A, (220 V) 6 A, (110 V) 10 A, (50 V) 10 A, (24 V) 10 AAC-15: (440 V) 1 A, (220 V) 3 A, (110 V) 5 A, (50 V) 7 A, (24 V) 10 ADC-12: (220 V) 1.1 A, (110 V) 2.2 A, (48 V) 5 A, (24 V) 10 ADC-13: (220 V) 0.6 A, (110 V) 1.1 A, (48 V) 2 A, (24 V) 10 A
Actuator Type	Flush
Bezel Material	Plastic
Lamp Colour	Red
Lens Colour	Red
Switching Function	Momentary
IP Rating	IP65

IDEC HW1L-M1F11M4R-K Illuminated Pushbutton Kit Transformer 22mm Flush Momentary Red 240/6VAC/DC 1NO+1NC
