Specifications

Number of Poles	2
Product Type	Power Relay
Brand	IDEC
Timing Range	30 ms
Contact Configuration	2 DPST
Rated Current	25 A
Rated Power	1.9 W
Rated Voltage	12 VDC
Terminal Type	Screw
Response Time	1000 ms
Mechanical Durability	1000000 Operations
Contact Material	Ag Alloy
Mounting Type	DIN Rail
Vibration Resistance acc. To IEC/EN 60068-2-6	10-55 Hz
Weight	90-135 g
Humidity	5-85%
Operating Temperature	-25 to 55 deg C
IP Rating	IP40
Standards and Approvals	CE, cRuUS, RoHS, VDE
