Specifications

Product Type	Power Relay
Brand	IDEC
Series	RN
Actuating Voltage	92 V AC
Electrical Endurance	100000 Operations
No. of N/C Contacts	4
No. of N/O Contacts	4
Timing Range	20 ms
Contact Configuration	4PDT
Electrical Connection	Blade
Rated Current	3 A
Rated Power	1.2 VA
Rated Voltage	115 VAC
Change-Over Contacts	4PDT
Mechanical Durability	10000000 Operations
Rated Voltage (Coil)	115 V AC
Contact Material	Ag Alloy
Mounting Type	With Socket (DIN Rail/PCB)
Vibration Resistance acc. To IEC/EN 60068-2-6	10-55 Hz
Depth	28 mm
Height	36 mm
Weight	35 g
Width	21.5 mm
Humidity	35-85%
Operating Temperature	–40 to +70°C (no freezing)
Standards and Approvals	CE, cRUus
