Specifications

Product Type	Power Relay
Brand	IDEC
Electrical Endurance	200000 Operations
Timing Range	25 ms
Contact Configuration	DPDT
Rated Current	10 A
Rated Voltage	240 VAC
Terminal Type	Blade
Response Time	100 ms
Mechanical Durability	10000000 Operations
Contact Material	Silver
Model	Side Flange
Vibration Resistance acc. To IEC/EN 60068-2-6	10-55 Hz
Weight	82 g
Humidity	5-85%
Operating Temperature	-25 to 40 deg C
Standards and Approvals	CE, CSA
