<p>The YW Series Pushbutton is a robust and reliable choice for industrial and commercial applications, designed to meet demanding operational requirements. This pushbutton operates at a rated voltage of 230/240 VAC/DC and features an illuminated design with an amber built-in LED, ensuring visibility even in low-light conditions. The compact dimensions—30 mm width, 41.4 mm height, and 64.8 mm depth—make it suitable for various installation environments.</p><p>Built to withstand the elements, this pushbutton boasts an IP65 degree of protection on the front face, safeguarding against dust ingress and low-pressure water jets from any direction. The terminal side is rated at IP20, providing basic protection against finger contact with live parts. It operates reliably within a temperature range of -20 to 55 degrees Celsius and can be stored safely between -40 to 85 degrees Celsius.</p><p>For those concerned about durability under mechanical stress, this pushbutton offers excellent vibration resistance from 5-55 Hz and shock resistance up to 10 g/ms. Its mechanical life extends up to five million operations for single contact blocks and one million operations for double contact blocks, making it ideal for high-frequency usage scenarios.</p><p>The electrical specifications are equally impressive; it carries a rated insulation voltage of 600 V and supports a continuous current rating of up to 10 A. With an insulation resistance exceeding 100 MOhm, safety is assured during operation. The pushbutton comes with a screw terminal type that facilitates secure connections.</p><p>This model fits into standard cutouts with its diameter set at 22 mm while maintaining ease of use through its extended actuator type configured as momentary function with contacts arranged in a format of one normally open (1NO) plus one normally closed (1NC). Constructed using silver as the contact material enhances conductivity and reliability over time.</p><p>Compliant with international standards including cULus listing CE marking UKCA certification and CCC certification this product aligns well with global quality expectations ensuring peace of mind regarding regulatory compliance across different regions.</p><p>Additionally constructed from durable plastic bezel material it maintains functionality within humidity levels ranging from 45% to 85%. Whether you&#39;re upgrading existing systems or designing new installations the YW Series Pushbutton provides both performance efficiency alongside long-term dependability meeting varied technical needs without compromise on quality or safety standards.</p>
