Specifications

Product Type	Fuse link
Brand	Mersen
Application	General purpose low-voltage distribution protection
Utilization Category	gG
Breaking Capacity	80 kA
Rated Current	50 A
Rated Voltage	415 V AC
Speed Class	gG
Body Style	Offset blade
Connection/Termination	Offset blade
Indicators	No
Material	Ceramic body, copper alloy contacts
Mounting	Clip-in / offset blade
Size Code	F2
Depth	15.2 mm
Height	39.5 mm
Length	69 mm
Weight	0.029 kg (Approx.)
Width	17.1 mm
Standards and Approvals	EN 60269-2 section II; BS 88 part 6

IPD ES50 Unit Fuse-Link 50A 415VAC Clip-In BS88 Fuse 80kA gG gM
