Specifications

Product Type	Fuse link
Brand	Mersen
Application	Motor-start and low-voltage circuit protection
Utilization Category	gM
Breaking Capacity	80 kA
Rated Current	63M80 / 80 A
Rated Voltage	415 V AC
Speed Class	gM
Body Style	Offset blade
Connection/Termination	Offset blade
Indicators	No
Material	Ceramic body, copper alloy contacts
Mounting	Clip-in / offset blade
Size Code	F2
Depth	15.2 mm
Height	39.5 mm
Length	69 mm
Width	17.1 mm
Standards and Approvals	EN 60269-2 section II; BS 88

IPD ES63M80 Unit Fuse-Link 80A 415VAC Clip-In BS88 Fuse 80kA gG gM For: SC63 Holder
