Specifications

Product Type	Fuse Link
Brand	Mersen
Application	General purpose motor protection
Utilization Category	gM
Breaking Capacity	80 kA AC
Rated Current	20M25 A
Rated Voltage	550 V AC / 250 V DC
Speed Class	gM motor protection
Body Style	British Standard fuse-link IEC BS88 Type A1
Connection/Termination	Offset slotted bolted tags
Fixing Centres	44.5 mm
Indicators	No indicator
Material	Body: Ceramic, Terminal: Tin-Plated Copper
Mounting	Bolted / screwed into fuseholder or busbar
Size Code	A1
Length	56 mm
Weight	0.016 kg (Approx.)
Width	Ø 13.5 mm
Standards and Approvals	EN 60269-2 section II; BS 88 part 2; RoHS
