Specifications

Product Type	Fuse Link
Brand	Mersen
Series	BNS
Application	General purpose motor protection
Utilization Category	gM
Breaking Capacity	80 kA
Rated Current	32M40 A
Rated Voltage	415 V AC / 415 V DC
Body Style	Offset blade
Connection/Termination	Offset blades
Fuse Holder	SC32 holders
Indicators	without indicator
Material	Body: Ceramic
Mounting	Clip-in
Size Code	F1
Length	61 mm
Weight	0.0238 kg (Approx.)
Width	Ø 13.5 mm
Standards and Approvals	EN 60269-2, BS 88-2

IPD NS32M40 Unit Fuse-Link 40A 415VAC Clip-In BS88 Fuse 80kA gG gM
