IPD TIA16L Fuse Link 16A 415VAC Offset Slotted Bolted Tag 80kA 73mm gG For: RS32/63 RSM

Product Code: TIA16L

In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

Product Type British Standard offset tag fuse link
Brand IPD
Series TIA
Application General purpose circuit protection; suitable for RS32/63 and RSM holders
Utilization Category gG / gL
Breaking Capacity 80 kA
Rated Current 16 A
Rated Frequency 50/60 Hz
Rated Voltage 690 V AC / 460 V DC
Speed Class General purpose
Body Style Offset bolted tag
Connection/Termination Offset bolted tags
Fixing Centres 73 mm
Indicators without indicator
Material Ceramic fuse body; metal tags
Mounting Bolt-in fuse holder
Size Code BS88/A2
Height 21 mm
Length 84.5 mm
Weight 0.04825 kg
Width 21 mm
Standards and Approvals BS88-2; IEC 60269-2

Documents

IPD Product Catalogue V17
