Specifications

Product Type	Fuse link
Brand	IPD
Series	TSC
Application	High speed traction fuse for AC/DC traction applications.
Utilization Category	High speed / traction
Breaking Capacity	63 kA
Rated Current	50 A
Rated Voltage	1200 V AC / 660 V DC
Speed Class	High Speed
Body Style	Offset bolted tags
Connection/Termination	Offset bolted tags
Fixing Centres	124 mm
Fuse Holder	RSL63 fuse-holder
Indicators	without indicator
Mounting	Bolt-in
Size Code	26 x 139
Length	139 mm
Weight	0.1366 kg (Approx.)
Width	Ø 27 mm
Standards and Approvals	BS2692-1

IPD TSC50 Bolt-In High Speed Traction Fuse 50A 1200VAC 26mm Dia x 139mm L 63kA 124mm gL gG
