Specifications

Product Type	Fuse link
Brand	Mersen
Series	AJT
Application	Motor circuits, mains, feeders, branch circuits, lighting/heating loads, transformers and control panels
Utilization Category	Class J
Breaking Capacity	200 kA AC
Rated Current	60 A
Rated Frequency	50/60 Hz
Rated Voltage	600 V AC / 400 V DC
Speed Class	Time delay
Body Style	Cylindrical / ferrule
Connection/Termination	Ferrule end caps
Indicators	Non-indicating; SmartSpot indicator version available
Material	Fiberglass body; high-grade silica filler; metal end caps
Mounting	Fuse holder / fuse block
Size Code	27 x 60
Height	60 mm
Weight	0.044 kg
Width	Ø 27 mm
Standards and Approvals	UL 248-8; CSA C22.2 No. 248.8; IEC 60269-2-1

Mersen AJT60 Power Fuse 60A 600/400VAC/DC Class J 27mm Dia x 60.5mm L Ferrule Terminal Class J 200kA
