Specifications

Product Type	Fuse Link
Brand	Mersen
Series	NH
Application	General purpose cable and line protection
Utilization Category	gG
Breaking Capacity	120 kA
Rated Current	80 A
Rated Voltage	500 V AC / 250 V DC
Body Style	Square body
Connection/Termination	Knife blade
Indicators	Double indicator
Material	Body:Ceramic, silver-plated copper contacts
Size Code	NH000
Depth	52.5 mm
Length	78.5 mm
Weight	0.13 kg (Approx.)
Width	21 mm
Standards and Approvals	IEC 60269-1 and -2, VDE 0636 Part 201

Mersen NHG00-080 Blade Type Fuse Link 80A 500VAC NH000 20.8mm 120kA For: 00 Bases and Disconnects
