Specifications

Product Type	Fuse Link
Brand	Mersen
Series	NH
Application	General purpose cable and line protection
Utilization Category	gG
Breaking Capacity	120 kA
Rated Current	315 A
Rated Voltage	500 V AC / 250 V DC
Body Style	Square body
Connection/Termination	Knife blade
Indicators	Double indicator
Material	Body:Ceramic, silver-plated copper contacts
Size Code	NH1
Length	135 mm (approx.)
Weight	0.42 kg (Approx.)
Width	39.5 mm (approx.)
Standards and Approvals	IEC 60269-1 and -2, VDE 0636 Part 201

Mersen NHG1-315 Blade Type Fuse Link 315A 500VAC NH1 39.5mm 120kA
