Specifications

Product Type	RF Equipment Protection up to 3GHz
Brand	Novaris
Series	CT
Application	Signal, RF Protection
Connection Type	TNC
Max. Working Frequency	3 GHz
Power Rating	150 W
Sparkover Voltage	230 V DC
Rated Frequency	3 GHz
Rated Voltage	230 VDC
Voltage Protection Level Up	820 V
Max. Discharge Current Imax (8/20µs)	20 kA
Connection Orientation	M/F
Mounting Method	Bulkhead
Depth	54 mm
Height	21 mm
Weight	60 g
Width	21 mm
Operating Temperature	-40°C to 70°C
IP Rating	IP67
