Specifications

Product Type	Hybrid Spark Gap Arrester
Brand	NOVARIS
Connection Type	Shunt
Lightning Impulse Current Iimp (10/350µs)	25 kA
No. of Phases	1
Contact Configuration	SPDT
Modes of Protection	L-N
Rated Current	250 kA
Rated Frequency	50 Hz
Rated Voltage	230 V
Response Time	<100 ns
Display	LED
Material	Metal
Mounting Type	Panel, TS35 DIN
Depth	70 mm
Height	200 mm
Weight	1.2 kg
Width	60 mm
Humidity	5-95%
Operating Temperature	-40 to 70 deg C
IP Rating	IP20
Standards and Approvals	EC 61643-11 Class I, AS/NZS 1768 Category C, IEEE C62.41 Category C, IEC 1000-4-5, UL1449 Fourth Edition

Novaris HSG1-25-480 Hybrid Spark Gap Arrester 25kA 1 PH 250kA 230V 50Hz TS35 DIN Mount 200mm H Metal IP20
