Specifications

Product Type	Surge Protection
Brand	NOVARIS
Series	IDD3
Connection Type	Shunt
Lightning Impulse Current Iimp (10/350µs)	12.5 kA
No. of Phases	3
Communication Ports	1
Modes of Protection	L-L, L-PE
Rated Current	100 kA (L-PE)
Rated Short Circuit Current	50 kA
Rated Voltage	400 VAC
Response Time	<5 ns (L-PE)
Voltage Protection Level Up	<800 V
Display	LED Power and Thermal Failure
Material	Aluminium
Mounting Type	TS35 DIN Rail
Tightening Torque	2 N-m
Depth	95 mm
Height	70 mm
Weight	550 g
Width	72 mm
Humidity	5-95%
Operating Temperature	-40 to 70 deg C
IP Rating	IP20
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, IEEE 62.41.2:2002, UL 1449 3rd Edition
