Specifications

Product Type	Delta Connected Surge Diverter
Brand	Novaris
Series	IDD3
Application	Power, Distribution Boards and Domestic MSB, Commercial and Industrial
Connection Type	Shunt
Lightning Impulse Current Iimp (10/350µs)	4 kA
Max. Backup Fuse	32 A
Max. Continuous Operating Voltage (AC/DC)	300 V AC, 420 V DC
No. of Phases	3
Communication Ports	1
Modes of Protection	L-L, L-PE
Rated Current	50 kA (L-PE)
Rated Short Circuit Current	25 kA
Rated Voltage	220 VAC
Nominal Voltage	220 V AC
Voltage Protection Level Up	1300 V
Max. Discharge Current Imax (8/20µs)	50 kA
Short Circuit Current Rating	25 kA
Nominal Discharge Current Inom (8/20µs)	20 kA
Display	LED Power and Thermal Failure
Enclosure Material	Black powdercoat
Material	Aluminium
Mounting Method	TS35 DIN Rail
Mounting Type	TS35 DIN Rail
Terminal Size	16 mm2
Tightening Torque	2 N-m
Depth	95 mm
Height	70 mm
Weight	320 g
Width	54 mm
Humidity	5-95%
Operating Temperature	-40°C to 70°C
IP Rating	IP20
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, IEEE 62.41.2:2002, UL 1449 3rd Edition
