Specifications

Product Type	IS-LCP Intrinsically Safe Load Cell Protector
Brand	Novaris
Series	IS-LCP
Application	Signal, Process Control Hazardous Areas, Loadcells
No. of Lines/Pairs	4 or 6
Modes of Protection	Transverse and Common Modes
Rated Current	0.25 kA
Rated Voltage	18 VDC
Voltage Protection Level Up	45 V
Max. Discharge Current Imax (8/20µs)	250 A
Max. Continuous Operating Voltage (DC)	18 V
Max. Continuous Operating Voltage (AC)	12 V
Material	Aluminium
Mounting Method	Free standing
Terminal Size	2.5 mm2
Tightening Torque	0.5 N-m
Depth	160 mm
Height	56 mm
Weight	600 g
Width	66 mm
Humidity	5-95%
Operating Temperature	-40°C to 85°C
IP Rating	IP67

Novaris IS-LCP-18 Load Cell Protector 0.25kA 18VDC 116mm W 56mm D 65mm H Aluminium IP65
