Novaris KP1-48 Telephone Protector 10kA 56VDC KRONE LSA-PLUS 21mm W 9.5mm D 53.3mm H ABS Black EDM IP20

Product Code: KP1-48

  • Surge protection with 10 kA rated current
  • Compatible with KRONE LSA-PLUS connections
  • IP20 rated for indoor environments
  • Fast response time of <5 ns
  • Operates in -40 to 85°C temperature range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Telephone Protector
Brand NOVARIS
Capacitance 18 pF
Connection Type KRONE LSA-PLUS
Degree of Protection IP20
Depth 9.5 mm
Height 53.3 mm
Humidity 5-95%
Material ABS, Black EDM
Modes of Protection Transverse and Common Modes
Mounting Type KRONE LSA-PLUS
Operational Temperature -40 to 85 deg C
Rated Current 10 kA
Rated Voltage 56 VDC
Resistance 2.7 Ohm
Response Time <5 ns
Standards and Approvals IEC 61643-21:2012, AS/NZS 1768:2007, UL 1449 3rd edition and UL 497B, ITU-T K.44: 2012, AS/CA S008:2010, AS/NZS 4117:1999
Weight 6.5 g
Width 21 mm

Description

<p>When it comes to safeguarding your industrial and commercial systems from electrical surges, this surge protector stands out with its robust specifications tailored for Australian conditions. Designed with precision, it offers reliable protection that aligns with stringent industry standards.</p><p>This surge protector operates at a rated voltage of 56 VDC and can handle a substantial current of 10 kA, making it suitable for various applications requiring dependable surge protection. Its connection type is the KRONE LSA-PLUS, known for its secure and efficient connectivity in telecommunications and data networks.</p><p>The device boasts an IP20 degree of protection, ensuring safety against solid objects larger than 12 mm but not against moisture. With dimensions measuring 21 mm in width, 53.3 mm in height, and just 9.5 mm in depth, this compact unit is easy to integrate into existing setups without demanding excessive space.</p><p>One of the standout features is its impressive operational temperature range from -40 to 85 degrees Celsius. This makes it highly adaptable to both extreme cold and heat environments typical in many parts of Australia.</p><p>Compliance with international standards such as IEC 61643-21:2012 ensures this product meets global expectations for performance and safety. Additionally, local compliance through AS/NZS 1768:2007 further assures users of its suitability within Australia’s regulatory framework.</p><p>Weighing only 6.5 grams, the surge protector&amp;#39;s lightweight design does not compromise on durability or function. Constructed from ABS material with Black EDM finish, it promises longevity while maintaining an aesthetically professional appearance.</p><p>With a rapid response time of less than five nanoseconds (&amp;lt;5 ns), this device swiftly mitigates potential damage caused by transient surges. It effectively protects against both transverse and common modes—ensuring comprehensive coverage across different types of electrical disturbances.</p><p>Capacitance at a low level of 18 pF coupled with resistance set at 2.7 Ohms highlights its efficiency in minimizing interference while maintaining clear signal integrity—a crucial factor for sensitive electronic equipment.</p><p>Operating efficiently within humidity levels ranging between 5% to 95%, this surge protector remains reliable under diverse environmental conditions—a testament to its robust engineering suited for varied Australian climates.</p><p>In summary, whether you’re looking to protect critical infrastructure or maintain seamless operations across your facilities—this well-engineered surge protector delivers essential safeguards backed by rigorous certifications such as UL1449 (3rd Edition) &amp;amp; ITU-T K44:2012 among others—ensuring peace-of-mind performance where you need it most.</p>
