Specifications

Product Type	Modular plug protector VDSL
Brand	Novaris
Series	MPP
Application	Signal, Network and CCTV
Lightning Impulse Current Iimp (10/350µs)	1.25 kA
No. of Lines/Pairs	1 pair
Rated Current	5 kA (Per Line)
Rated Voltage	200 VDC
Line Resistance	0.1 Ohm
Voltage Protection Level Up	950 V
Max. Discharge Current Imax (8/20µs)	5 kA
Max. Continuous Operating Voltage (DC)	230 V
Max. Continuous Operating Voltage (AC)	162 V
Mounting Method	Free standing
Depth	80 mm
Height	28 mm
Width	27 mm
Operating Temperature	-40°C to 70°C
IP Rating	IP20

Novaris MPP-VDSL Telephone Line Protector With Spacer and Screw Adaptor 1.25kA 5kA 200VDC 26mm H
