Specifications

Product Type	Plug-in Surge Filter
Brand	Novaris
Series	PP10A
Application	Power, Appliance Protection, Plug in Filters (Australian)
Connection Type	Series
Lightning Impulse Current Iimp (10/350µs)	6.25 kA
Max. Backup Fuse	10 A
Max. Continuous Operating Voltage (AC/DC)	275 V AC
Max. Load Current	10 A
No. of Phases	1
Suitable For	Industrial
Modes of Protection	L-N, L-PE, N-PE
Rated Current	50 kA
Rated Voltage	275 VAC (L-N, N-PE, L-PE)
Nominal Voltage	230 V AC
Voltage Protection Level Up	700 V
Max. Discharge Current Imax (8/20µs)	50 kA
Short Circuit Current Rating	25 kA
No. of Outlets	4
Nominal Discharge Current Inom (8/20µs)	20 kA
Mounting Method	Free standing
Mounting Type	Free Standing
Depth	137 mm
Height	60 mm
Weight	1.3 kg
Width	205 mm
Humidity	0-90%
Operating Temperature	-40°C to 70°C
IP Rating	IP20
Standards and Approvals	IEC 61643-11, AS/NZS 1768, IEEE C62.41, IEC 1000-4-5
