Specifications

Product Type	Network Protectors
Brand	Novaris
Series	RJ45-CAT6
Application	Protection of equipment connected to twisted pair network cabling systems
Connection Type	RJ45 Socket
No. of Lines/Pairs	4 pairs and shield
Modes of Protection	Transverse and Common Modes
Rated Current	5 kA
Rated Voltage	4 VAC
Terminal Type	RJ45 Socket
Response Time	<5 ns
Voltage Protection Level Up	20 V @ 1 kV/ µs
Max. Discharge Current Imax (8/20µs)	5 kA
Max. Continuous Operating Voltage (DC)	6 V
Max. Continuous Operating Voltage (AC)	4 V
Housing Material	Aluminium
Material	Nylon
Mounting Method	TS35 DIN Rail/Flying
Mounting Type	TS35 DIN Rail
Terminal Size	RJ45
Depth	80 mm
Height	36 mm
Length	178 mm
Weight	180 g
Width	27 mm
Humidity	5-95%
Operating Temperature	-40 °C - 85°C
IP Rating	IP20
Standards and Approvals	IEC 61643-21:2012, AS/NZS 1768:2007
