Specifications

Product Type	Surge Circuit Breaker
Brand	NOVARIS
Series	SCB
Application	Main and distribution switchboards
Lightning Impulse Current Iimp (10/350µs)	25 kA
Rated Current	25 kA
Rated Short Circuit Current	25 kA
Rated Voltage	230 VAC
Material	Polycarbonate
Mounting Type	DIN Rail
Height	72 mm
Length	85 mm
Weight	0.204 kg
Width	35 mm
Humidity	5-95%
Operating Temperature	-25 to 60 deg C
IP Rating	IP20
Standards and Approvals	IEC61643-11, IEC60898-1
