Specifications

Product Type	Surge Diverter
Brand	NOVARIS
Series	SD1
Connection Type	Shunt
Lightning Impulse Current Iimp (10/350µs)	19 kA (L-N)
No. of Phases	1
Communication Ports	1
Contact Configuration	SPDT
Modes of Protection	L-N
Rated Current	150 kA (L-N)
Rated Short Circuit Current	50 kA
Rated Voltage	230 VAC
Response Time	<25 ns (L-N)
Voltage Protection Level Up	<750 V
Display	Digital
Material	Metal
Mounting Type	TS35 DIN Rail
Tightening Torque	0.5 N-m, 2 N-m
Depth	120 mm
Height	256 mm
Weight	505 g
Width	176 mm
Humidity	5-95%
Operating Temperature	-40 to 70 deg C
IP Rating	IP20
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002

Novaris SD1-150-275-M Surge Diverter 19kA 1-P 1 PH 150kA 230VAC TS35 Metal IP20
