Novaris SD3-150-275-N Surge Diverter 19kA 30kA 3 PH 150kA 150kA 230VAC Mount Aluminium IP20

Product Code: SD3-150-275-N

1

Specifications

Product Type	Surge Diverter
Brand	NOVARIS
Series	SD3
Connection Type	Shunt
Contact Configuration	SPDT
Degree of Protection	IP20
Depth	200 mm
Display Type	Digital
Fuse Rating	80 A
Height	80 mm
Humidity	5-95%
Interrupt Rating	100 A
Lightning Impulse Current	19 kA (L-N), 30 kA (N-PE)
Material	Aluminium
Modes of Protection	L-L, L-N, N-PE
Mounting Type	Panel
Number of Ports	1
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	150 kA (L-N), 150 kA (N-PE)
Rated Short Circuit Current	50 kA
Rated Voltage	230 VAC
Response Time	<25 ns (L-N), <100 ns (N-PE)
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Tightening Torque	0.5 N-m, 2 N-m
Voltage Protection Level	<750V (L-N)
Weight	2.7 kg
Width	200 mm

Documents

IPD Product Catalogue V17

Installation

CAD Blocks & Dimensions

Dimensions

Dimensions

Dimensions
