Novaris SDD3-10-31-RPU Surge Protector 50kA 24VDC Shunt TS35 Metal IP20

Product Code: SDD3-10-31-RPU

1

Specifications

Product Type	Surge Protector
Brand	NOVARIS
Series	SDD3
Connection Type	Shunt
No. of Lines/Pairs	2
Modes of Protection	All Mode
Rated Current	50 kA
Rated Voltage	24 VDC
Response Time	<5 ns
Voltage Protection Level Up	<150 V
Display	LED Status
Material	Metal
Mounting Type	TS35 DIN Rail
Tightening Torque	1 N-m
Depth	70 mm
Height	95 mm
Weight	230 g
Width	36 mm
Operating Temperature	-40 to 65 deg C
IP Rating	IP20
Standards and Approvals	IEC 61643-1, AS/NZS 1768

Documents

IPD Product Catalogue V17
