Novaris SFD1-20-100-275-A Surge Filter 6.25kA 15kA 1 PH 20A 230VAC TS35 Panel Mount Metal IP20

Product Code: SFD1-20-100-275-A

1

Specifications

Product Type	Surge Filter
Brand	NOVARIS
Series	SFD1
Degree of Protection	IP20
Display Type	LED Status
Fuse Rating	20 A
Height	69 mm
Humidity	5-95%
Interrupt Rating	100 A
Length	115 mm
Lightning Impulse Current	6.25 kA (L-N), 15 kA (N-PE)
Material	Metal
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	TS35 DIN Rail, Panel
Operational Temperature	-40 to 70 deg C
Phase	1
Rated Current	20 A
Rated Short Circuit Current	25 kA
Rated Voltage	230 VAC
Response Time	<100 ns (N-PE)
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Suitable For Use With	32 A Circuits
Tightening Torque	0.5 N-m, 2 N-m
Voltage Protection Level	<600V (L-N)
Weight	625 g
Width	72 mm

Documents

IPD Product Catalogue V17

Manual

CAD Blocks & Dimensions

Dimensions

Dimensions

Dimensions
