Specifications

Product Type	Combined Power and Signal Protector
Brand	NOVARIS
Connection Type	Series
Degree of Protection	IP20
Depth	70 mm
Height	116 mm
Humidity	5-95%
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	TS35 DIN Rail
Operational Temperature	-40 to 85 deg C
Phase	1
Rated Current	10 kA Power, 20 kA Signal
Rated Frequency	50/60 Hz
Rated Voltage	110 VAC
Tightening Torque	0.5 N-m
Voltage Protection Level	<450 V
Weight	200 g
Width	18 mm

Novaris SFD1-6-10-130-C Combined Power and Signal Protector 1 PH 10kA Power 20kA Signal 110VAC 50/60Hz TS35 116mm H IP20
