Specifications

Product Type	Combined Power and Signal Protector
Brand	NOVARIS
Series	SFD-C
Connection Type	Series
Degree of Protection	IP20
Depth	70 mm
Height	116 mm
Humidity	5-95%
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	TS35 DIN Rail
Number of Poles	2
Operational Temperature	-40 to 85 deg C
Phase	1
Rated Current	10 kA Power, 20 kA Signal
Rated Frequency	50/60 Hz
Rated Voltage	40 VAC
Standards and Approvals	IEC 61643-11, AS/NZS 1768, IEEE C62.41, IEC 1000-4-5, IEC 61643-21
Tightening Torque	0.5 N-m
Voltage Protection Level	<180 V
Weight	200 g
Width	18 mm

Novaris SFD1-6-10-50-C Combined Power Signal Protector 2-P 1 PH 10 kA Power 20 kA Signal 40VAC 50/60 Hz TS35 116mmH IP20
