Specifications

Product Type	Surge Diverter
Brand	Novaris
Series	SFD3
Application	Critical installations, sensitive electronics and computer equipment with single phase loads up to 32A
Max. Backup Fuse	10A
No. of Poles (Total)	3
Nominal Voltage	230V
Voltage Protection Level Up	<1000V
Maximum Discharge Current Imax (8/20µs)	50kA
Mounting Method	DIN Rail
Depth	69 mm
Height	95 mm
Width	180 mm
Operating Temperature	-40°C - 70°C
IP Rating	IP20
