Specifications

Product Type	Surge Filter
Brand	NOVARIS
Series	SFM1
Connection Type	Series
Lightning Impulse Current Iimp (10/350µs)	25 kA (L-N)
No. of Phases	1
Communication Ports	2
Modes of Protection	L-N, L-PE, N-PE
Rated Current	200 kA (L-N)
Rated Short Circuit Current	50 kA
Rated Voltage	230 VAC
Voltage Protection Level Up	<3.6 kA (L-N)
Display	LED Power and Thermal Failure
Mounting Type	Panel
Tightening Torque	0.5 N-m, 1 N-m
Depth	110 mm
Height	344 mm
Weight	12 kg
Width	284 mm
Humidity	5-95%
Operating Temperature	-40 to 70 deg C
IP Rating	IP20
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007
